19
SELECTION
DESCRIPTION
r-2
Reset Setpoint output 2
r-3
Reset Setpoint output 3
r-4
Reset Setpoint output 4
r-34
Reset Setpoint outputs 3 & 4
r-234
Reset Setpoint outputs 2, 3 & 4
r-ALL
Reset all Setpoint outputs
Print Request
LINE 2 DISPLAY SCROLL ENABLE/TIME
NO
1
to
15
seconds
If Line 2 Display Scrolling is desired, set the scroll time in seconds.
LINE 2 UNITS MNEMONIC(S)
OFF
LAbEL
CUSt
FACt
Lb-FAC
L1-FAC
Lb-CSt
Lb Ln1
Select the mode for Line 2 Units Mnemonic(s). See LINE 2 UNITS
MNEMONIC DIAGRAM for programming details.
SELECTION
MODE
DESCRIPTION
OFF
OFF
No Line 2 mnemonics shown.
LAbEL
LABEL
Single programmable mnemonic shown as a
separate item in the Line 2 Display loop. No
individual mnemonics are shown with the other
Line 2 Display values.
CUSt
CUSTOM
Individual Custom programmable mnemonics
shown with each value in the Line 2 Display loop.
FACt
FACTORY
Individual Factory default mnemonics shown with
each value in the Line 2 Display loop.
Lb-CSt
LABEL &
CUSTOM
A programmable mnemonic shown as a separate
item in the Line 2 Display loop. Also, individual
Custom programmable mnemonics shown with
each value in the Line 2 Display loop.
Lb-FAC
LABEL &
FACTORY
A programmable mnemonic shown as a separate
item in the Line 2 Display loop. Also, individual
Factory default mnemonics shown with each
value in the Line 2 Display loop.
Lb Ln1
LINE 1
INDEXED
LABELS
Individual programmable mnemonics, indexed to
the Line 1 Display value, are shown as a
separate item in the Line 2 Display loop. These
same mnemonics are also shown with each
value in the Line 2 Display loop.
L1-FAC
LINE 1
INDEXED
LABELS &
FACTORY
Individual programmable mnemonics, indexed to
the Line 1 Display value, are shown as a
separate item in the Line 2 Display loop. Also,
individual Factory default mnemonics are shown
with each value in the Line 2 Display loop.
The characters available for the programmable modes include:
A b C d E F G H I J k L M N O P q r S t U W Y Z 0 1
2 3 4 5 6 7 8 9 a c e g h i
m
n o u
w
- = [ ] / ° _ blank
PROGRAMMING SECURITY CODE
000
to
250
To activate either the Parameter or Hidden Parameter display loops, a security
code (1-250) must be entered. If a “0” security code is programmed, pressing the
P key takes you directly to the Full Programming Mode.
The Security Code determines the programming mode and the accessibility
of programming parameters. This code can be used along with the Program
Mode Lock-out (PLOC) in the User Input Function parameter (Input [User]
module).
Two programming modes are available. Full Programming Mode allows all
parameters to be viewed and modified. Parameter display loop mode provides
access to those selected parameters, that can be viewed and/or modified without
entering the Full programming mode.
The following chart indicates the levels of access based on various CodE and
User Input PLOC settings.
SECURITY
CODE
USER INPUT
CONFIGURED
USER INPUT
STATE
WHEN P KEY IS
PRESSED
FULL PROGRAMMING
MODE ACCESS
0
not
PLOC
———— Full Programming
Immediate Access
0
PLOC
Not Active Full Programming
Immediate Access
0
PLOC
Active
Enter Parameter
Display Loop
No Access
>0
not
PLOC
———— Enter Parameter
Display Loop
After Parameter
Display Loop with
correct code # at
COdE
prompt.
>0
PLOC
Not Active Full Programming
Immediate Access
>0
PLOC
Active
Enter Parameter
Display Loop
After Parameter
Display Loop with
correct code # at
COdE
prompt.
ScroLL
NO
Ln2
UNItS
FACt
Ln2
Two character spaces are required to display this character.
COdE
0
dSP
P
LINE 2 UNITS MNEMONIC DIAGRAM (9-DIGITS)
Edit
NO
P
Edit
CSt
NO
P
UNItS
Ln2
OFF
COdE
Ln2
000
UNItS
Ln2
LAbEL
Edit
YES
UNItS
Ln2
CUSt
Edit
INPUt
Unit 1
1
Unit 2
2
Unit 9
9
Edit
LO
P
P
P
P
Unit 1
1
Unit 2
2
Unit 9
9
P
P
P
P
P
P
Unit 1
1
Unit 2
2
Unit 9
9
P
P
P
P
Lb
Lb
Lb
Lb
Lb
CSt
CSt
INP
INP
INP
Lo
Lo
Lo
(Unit 3 thru 8)
(Unit 3 thru 8)
(Unit 3 thru 8)
(returns to currently selected value)
P
UNItS
Ln2
FACt
Lb-CSt
Lb-CSt
Lb-FAC
Lb Ln1
L1-FAC
F1
F2
F1
F2
F1
F2
GrOSS
tArE
tOtAL
HI
