User's Guide ______________________________________________________________________
NOTE When installing WMT700 to the side of a mast, make sure that the
mounting kit is positioned at the top level of the mast. See Figure 26
below.
1006-077
Figure 26 WMT700 on Side of Pole Mast
The following numbers refer to Figure 26 above:
1 = FIX70 mounting kit
2 = WMT700 wind sensor
3 = Mounting screw in final position
4 = U-bolt and nut (M8DIN934-A4) in horizontal slot
