Using WS425 Cables with Adapters
If a retrofit installation using WMT700 cables is not possible,
there are adapters available for most situations.
- Adapter Cable for WS425 Serial (227569SP)
- Adapter Cable for WS425 Analog Frequency Output
(227570SP)
- Adapter Cable for WS425 Analog Voltage Output (227571SP)
The adapter cable specifications in this section apply for both
heated and non-heated versions of WMT700.
NOTE FIX30 is not compatible with adapter cables due to the small diameter of
the mast.
Adapter Cable for WS425 Serial Output
The Adapter Cable for WS425 Serial (227569SP) can be used
with the WS425 cables ZZ45203 and 010411.
Table 31 below lists the adapter pin-outs and signal descriptions
as they appear on their user guides for both WMT700 and WS425
connectors.
Table 31 Pin-Outs for WS425 Serial Adapter Cable
(227569SP)
WMT700
Connector
Pin WMT700 Signal
Description WS425
Connector
Pin WS425 Signal
Description WS425
Wire
Color
1 Operating Power
Supply 11 +12 VDC Brown
3 COM2: Rx-/
RS232RX 10 Data in (RxD) (R-)
(RT-) Blue
4 COM2: Tx-/
RS232TX 9 Data out (TxD) (T-)
(RT-) Red
5 Heater Power
Supply 16 +36 VDC Gray/Pink
7 Heater Power
Supply Ground 3 GND Green
10 COM2:
Communications
Ground 8 GND Yellow
11 Operating Power
Supply Ground 1 GND Black
14 COM2: Tx+ 12 Data out (T+) (RT+) White
15 COM2: Rx+ 14 Data in (R+) (RT+) Pink
