Appendix B ________________________________________________ Typical System Environments
APPENDIX B
TYPICAL SYSTEM ENVIRONMENTS
This appendix lists the most typical WMT700 system
environments.
Figure 54 below shows a system in which the weather station is
connected to COM2, while COM1 is left for service and
maintenance purposes only. This is the recommended setup for
WMT700 serial communications.
1003-051
Figure 54
System Environment with Serial Port COM1
Only
VAISALA _______________________________________________________________________ 197
