Chapter 4 ________________________________________________________________ Installation
Adapter Cable for WS425 Analog Voltage
Output
The Adapter Cable for WS425 Analog Voltage Output
(227571SP) can be used with the WS425 cable ZZ45204. Table
33 below lists the adapter pin-outs and signal descriptions as they
appear on their user guides for both WMT700 and WS425
connectors.
Table 33 Pin-Outs for WS425 Analog Voltage Output
Adapter Cable
WMT700
Connector
Pin WMT700 Signal
Description WS425
Connector
Pin WS425 Signal
Description WS425
Wire
Color
1 Operating Power
Supply 11 +12 VDC Brown
2 Analog Output
AOUT2, Wind
Direction 13 WD Vout Gray
5 Heater Power
Supply 16 +36 VDC Gray/
Pink
7 Heater Power
Supply Ground 3 GND Green
11 Operating Power
Supply Ground 1 GND Black
12 Analog Output
Ground 8 GND Yellow
13 Analog Output
AOUT1, Wind
Speed 15 WS Vout Violet
17 Reference Input
for AOUT2 12 WD Vref in White
