User's Guide ______________________________________________________________________
Parameter
Name Default
Value Allowed Values Units Description
com1_baud
com2_baud 4 0 = 300
1 = 1200
2 = 2400
3 = 4800
4 = 9600
5 = 19200
6 = 38400
7 = 57600
8 = 115200 Baud rates for serial ports COM1 and
COM2. Changes take effect only after
reset or the RESET command.
Note that a low bit rate can affect
measurement timing, if WMT700 cannot
send the data message before a new
measurement starts.
com1_data
com2_data 8 7 = 7 data bits
8 = 8 data bits Data bits for serial ports COM1 and
COM2. Changes take effect only after
reset or the RESET command.
com1_delay
com2_delay 20 0 … 10000 ms COM1 and COM2 Response delay in
milliseconds.
com2_interf
0 0 = RS-485
1 = RS-422
2 = SDI-12
3 = RS-232 Interface for serial port COM2. (The
interface for serial port COM1 cannot be
changed.)
com1_parity
com2_parity 0 0 = None
1 = Even
2 = Odd Parity for serial ports COM1 and COM2.
Changes take effect only after reset or
the RESET command.
com1_protocol
0 0 … 11 Protocol for serial port COM1.
0 = WMT700
2 = WS425 F/G ASOS
3 = WS425 A/B ASCII
4 = WS425 A/B NMEA Standard
5 = WS425 A/B NMEA Extended
6 = WS425 A/B WAT11
8 = MES12
11 = WMT700 NMEA MWV
com2_protocol 0 0 … 11 Protocol for serial port COM2.
0 = WMT700
1 = SDI-12
2 = WS425 F/G ASOS
3 = WS425 A/B ASCII
4 = WS425 A/B NMEA Standard
5 = WS425 A/B NMEA Extended
6 = WS425 A/B WAT11
8 = MES12
11 = WMT700 NMEA MWV
com1_stop
com2_stop 1 1 = 1 bit
2 = 2 bits Stop bits for serial ports COM1 and
COM2.
Changes take effect only after reset or
the RESET command.
freqType 0 0 = Push-pull
1 = Active pull-down
2 = Active pull-up AOUT1 frequency output type. Setting 1
requires external pull-up resistor.
Setting 2 requires external pull-down
resistor.
heaterOn 1 0 = Heater off
1 = Automatic Heater control. When the value is set to
1, WMT700 controls the heaters based
on the temperature and other conditions.
messages 1 0 = Disabled
1 = Enabled Response for parameter setting.
