Chapter 7 ____________________________________________________________ Technical Data

VAISALA_______________________________________________________________________ 77

Humidity

For more information on operating humidity range, see

Figure 12 on page

79

.

Oxygen

Response time (90 %)

Effect on accuracy with humidity compensation:

±0.006 % of reading / g/m

3

H

2

O below 1000 ppm CO

2

±0.02 % of reading / g/m

3

H

2

O above 1000 ppm CO

2

The values above only apply in normal ambient pressure.
Effect on accuracy without humidity compensation (typ.):

+0.05 % of reading / g/m

3

H

2

O

Effect on accuracy with oxygen compensation at 20.9 %O

2

:

±0.2 % of reading

Effect on accuracy without oxygen compensation (typ.):

-0.09 % of reading / %O

2

Table 10

Diffusion Model

Filter attached

Averaging (s)

Response (s)

Yes

0

75

Yes

10

80

Yes

30

82

No

0

<2

No

10

12

No

30

30

Table 11

Flow-through Model

Gas flow (l/min) Averaging (s)

Response (s)

0.3

0

26

0.3

10

34

0.3

30

44

1.2

0

8

1.2

10

15

1.2

30

23
