2-24
2.8 USING THE WHITE LIGHT ILLUMINATOR -
Continued
Under certain operating conditions, particularly at night, it
may be desirable to help prevent inadvertent emission of
white light energy. The White Light Lens Cap is provided for
this purpose. To install the White Light Lens Cap, stretch it
out and over the front of the White Light Illuminator so that it
is snug and firmly in place. See Figures 2-10 and 2-11.
2.9 LED STATUS INDICATOR
A Light Emitting Diode (LED) is incorporated into the body of
the MIPIM that provides indicators as shown in Table 2-7.
Figure 2-13 LED Status Indicator
LED STATUS
INDICATOR
