2-14
SECTION II
OPERATING INSTRUCTIONS
2.7 MODES OF OPERATION
Table 2-5 describes the modes of operation for the MIPIM.
Table 2-5 Modes of Operation
Position Mode Remarks
O OFF
The MIPIM will not operate.
Prevents inadvertent emission
of laser and white light energy.
VISIBLE
A
AIM
Class 3R
Visible Aim Laser is selected.
L LIGHT
White Light Illuminator is
selected.
D
DUAL
(Class 3R)
Visible Aim Laser is selected in
conjunction with the White
Light Illuminator.
INFRARED (IR)
AL
AIM LOW
Class 1
IR Aim Laser is selected in low
power.
DL
DUAL LOW
Class 1/3B
IR Aim Laser and IR Illuminator
are both selected at low power.
AH
AIM HIGH
Class 3B
IR Aim Laser is selected at
high power.
DH
DUAL HIGH
Class 3B
IR Aim Laser and IR Illuminator
are both selected at high
power.
