Table 2-4 Mounting Configurations and Weapon Offsets
Weapon Mount
Range
Zeroed To
10m Boresight
Target Offset
Squares
25m Target Zero
Offset Squares
M4/M4A1/
M16A4 MWS Top Rail
300m
VIS 1.8L / 1.5U
IR 1.8L / 2.6U IR 2.0R / 1.0U
M4/M4A1/
M16A4 MWS Left Rail
300m
VIS 2.0L / 2.7D
IR 3.4L / 2.7D IR 3.5R / 5.0U
M4/M4A1/
M16A4 MWS Right Rail
300m
VIS 3.4R / 0.7U
IR 4.7R / 0.7U IR 4.2L / 3.0U
M249
Short Barrel
Feed Tray
Cover Rail
400m
VIS 4.7L / 5.0U
IR 4.7L / 6.2U IR 2.0L / 7.0U
M249
Short Barrel
Left Side
Forward Rail
400m
VIS 7.5L / 4.5D
IR 8.5L / 4.5D IR 6.0R / 11.5U
M249
Short Barrel
Right Side
Forward Rail
400m
VIS 0.5R / 0.6D
IR 1.5R / 0.6D IR 2.0L / 11.7U
M249
Standard Barrel
Feed Tray
Cover Rail
400m
VIS 2.4L / 3.2U
IR 2.4L / 4.5U IR 1.0R / 5.0U
M249
Standard Barrel
Left Side
Forward Rail
400m
VIS 3.5L / 4.5D
IR 4.5L / 4.5D IR 7.3R / 7.3U
M249
Standard Barrel
Right Side
Forward Rail
400m
VIS 3.3R / 1.5D
IR 4.6R / 1.5D IR 2.2L / 5.7U
M240B MG
Feed Tray
Cover Rail
500m
VIS 2.0L / 1.3U
IR 2.0L / 2.8U IR 2.3R / 6.9U
M240B MG
Left Side
Forward Rail
500m
VIS 3.7L / 7.6D
IR 4.8L / 7.6D IR 3.0R / 17.0U
M240B MG
Right Side
Forward Rail
500m
VIS 4.5R / 3.8D
IR 5.8R / 3.8D IR 5.2L / 13.7U
M4/M4A1/M16A4
MWS w/ M203 Top Rail
300m
VIS 1.8L / 1.5U
IR 1.8L / 2.6U IR 1.0R / 1.0U
M4/M4A1/M16A4
MWS w/ M203 Left Rail
300m
VIS 2.2L / 2.7D
IR 3.4L / 2.7D IR 3.6R / 8.0U
M4/M4A1/M16A4
MWS w/ M203 Right Rail
300m
VIS 2.8R / 0.0
IR 4.4R / 0.0 IR 4.2L / 4.5U
