1-13
1.9 FEATURES AND CONTROLS - Continued
Table 1-3 List of Features and Controls - Continued
Key
Control/
Indicator
Function
13 Remote Jack /
Jack Plug
Provides an interface for the Remote
Cable Switch. The MIPIM comes with a
remote jack plug installed to protect the
remote jack from debris and moisture.
14 FIRE Button Used to actively emit laser radiation
and/or white light that corresponds with
the position of the Mode Selector.
15 Mode Selector Allows the user to select the desired
mode of operation for the MIPIM. When
switched to O (OFF), the MIPIM will not
emit laser or white light energy.
16 Safety Screw When installed in the lockout position, the
safety screw prevents the Mode Selector
from being turned to the high power laser
settings (i.e., AH, DH). Removal of the
safety screw allows for access to all Mode
Selector settings.
17 Rail Grabber
Bracket
Secures the MIPIM to a weapon equipped
with a MIL-STD-1913 rail.
