2.8 USING THE LASERS

Laser modes of operation are selected and activated as

described in section 2.7.

Illuminator Beam Size

The IR illumination beam may be varied from flood to spot by

rotating the Illuminator Focus Knob as shown in Figure 2-9.

Figure 2-9 IR Illuminator Focus Knob

SPOT

FLOOD
