1-12
1.9 FEATURES AND CONTROLS - Continued
Table 1-3 List of Features and Controls - Continued
Key
Control/
Indicator
Function
5 IR Aim Laser Used with night vision devices to provide
a precision aim point or to mark targets.
6 White Light
Illuminator
Provides a white light beam designed to
allow for facial recognition at 25 meters.
7 White Light Lens
Cap
When installed over the White Light
Illuminator, reduces the risk of inadvertent
emission of white light energy.
8 Boresight
Adjusters
Used to bring the MIPIM aim lasers into
azimuth and elevation alignment with the
barrel of the weapon.
9 Safety Screw
Storage Location
Allows for secure storage of the safety
screw after it has been removed from the
lockout position.
10 Battery Cap /
Compartment
Provides secure housing for the two 3-volt
DL123A batteries that power the MIPIM.
11 Tie-Down
Attachment Point
Allows for the attachment of a lanyard to
the MIPIM when used in the handheld
mode.
12 LED Status
Indicator
A Light Emitting Diode (LED) used to
indicate when the MIPIM is emitting laser
and/or white light energy, when the
battery power is low, and displays the
pulse rate during programming of the IR
Illuminator.
