1.9 FEATURES AND CONTROLS - Continued

Table 1-3 List of Features and Controls

Key

Control/

Indicator

Function

Tri-Function Lens

Cap

Serves the following three functions when

installed over the Tri-Laser Assembly:

a. Uses an Illuminator Diffuser to

spread the laser energy from the IR

Illuminator over an angle of

approximately 180 degrees,

allowing for illumination of a wider

area;

b. Prevents emission from the Visible

Aim Laser; and

c. Uses a Neutral Density Filter to

reduce scatter from the IR Aim

Laser.

IR Illuminator

Focus Knob

Used to vary the IR illumination beam

spread from flood to spot, based on the

range and size of the area to be

illuminated.

IR Illuminator

Used with night vision devices to provide

variable focused IR illumination of the

intended target area.

Visible Aim Laser Used to provide a precision aim point or

to positively identify targets at close range

during the day or night, without the need

of night vision devices. May also be used

for boresighting the MIPIM during daylight

hours.
