DiabloSport Trinity T-1000 Comprehensive User Manual User Manual
Page 9
DiabloSport Trinity Comprehensive User Manual Ver. 2.04
Page 9
Step 6:
The
Trinity
may
prompt
you
to
“turn
your
key
on,
but
don’t
start
engine”
and
then
ask
you
to
turn
the
key
on/off
a
few
times.
It
will
begin
flashing
your
vehicle
with
the
chosen
tune.
When
the
flash
process
is
complete,
the
button
and
Trinity
will
reboot.
DRIVE
YOUR
VEHICLE
WITH
THE
NEW
TUNE!!!
2.2- Modifying your Vehicle’s Tune
In the previous section we showed an example of installing a tune with
the Trinity. In this section we will go over how to modify the tune you
selected to reflect aftermarket parts you’ve installed on your vehicle
(such as larger gears or oversized tires).
Different vehicles have different tuning options in Trinity‐ it’s possible
that some of these options may not apply. If you have advanced
questions or you aren’t sure how modify a tune for the best results, no
need to worry: DiabloSport has a nationwide network of CMR
(ChipMaster Revolution) custom tuning dealers who are experts in
Electronic Fuel injection (EFI) tuning. To find a CMR dealer near you, log
on to our website www.diablosport.com and click the dealer locator.
Now let’s look at how to make some minor adjustments:
Step 1:
Make
sure
your
Trinity
is
plugged
in
to
the
OBD
II
port
on
your
vehicle
and
it
has
already
saved
an
original
backup
(See
Section 2.1
for
more
information).
Select
the
tune
you
previously
installed
in
the
vehicle
select
“Modify
Tune”
from
the
“Performance
Tune”
Menu
and
then
“Modify
Parameters”
Note: To restore any tunes you’ve modified back to factory settings, select “Reset
all parameters”
Step 2:
Now you are in the “Modify Tune” Menu. You can scroll through
the
list
of
adjustable
parameters
by
using
the
arrow
icons
on
the
left
hand
side
of
the
screen,
or
alternatively
with
the
buttons
to
the
right
of
the
Trinity’s
screen.
Choose
the
parameter
you
wish
to
modify
and
select
it
by
touching
it
on
the
Trinity
screen,
or
using
the
buttons
on
the
Trinity
and
clicking
the
option
with
the
center
button.
Step 3:
To
make
changes
to
the
parameter,
use
the
touch
screen
on
your
Trinity
and
touch
either
the
fine
or
coarse
adjustment
arrow
(Fine
adjustment
is
the
single
arrow,
Coarse
Adjustment
is
the
double
arrow).
The
numbers
on
the
bottom
right
represent
maximum
parameter
value
