DiabloSport
Trinity
Comprehensive
User
Manual
Ver.
2.04


Page
16


4.2- Creating a New Gauge Layout

Step  1:
 Touch
 the
 Trinity’s
 touch
 screen
 on
 the
 “Logging”
 button.
 In
 the

Live
Data
Menu,
you
have
the
choice
of
creating
a
new
log
file
(select
this

to
 add
 a
 new
 blank
 gauge
 layout
 page),
 “Open
 a
 Saved
 Log
 File”
 (See
section  3.1
),
 “Delete
 a
 Saved
 Log”,
 or
 “Delete
 a
 Saved
 Layout”.
 For
 this

example,
select
“Create
a
New
Log”.


Step 2: You
will
now
be
on
a
“blank”
gauge
layout
page.
Now
it’s
time
to

populate
your
gauge
page
with
new
gauges!
In
order
to
do
so,
select
the

“EDIT”
button
on
the
right
side
of
the
screen
(or
hit
button
2).


Step 3:
You
are
now
in
the
“Live
Data
Edit
Menu”.
This
menu
allows
you
to

add
 a
 new
 gauge
 to
 your
 existing
 gauge
 page,
 access
 your
 gauge
 pages

(different
 pages
 of
 custom
 gauge
 sets
 in
 the
 same
 layout),
 or
 close
 the

current
log
file
you
are
working
with.
For
this
example
press
“Add
a
New

Gauge”
to
bring
up
the
gauge
selection
screen.


Step 4: To
choose
a
gauge
type,
simply
touch
the
gauge
type
you
want
to

add
 (for
 more
 information
 on
 gauge
 types
 see
 section  2.1)
 to
 scroll

through
the
different
gauge
types
tap
the
arrow
icons
on
the
left
side
of

the
screen
or
use
the
arrow

buttons
to
the
right
of
the
Trinity
screen.

For

the
purposes
of
this
demonstration,
let’s
select
a
large
radial
and
then
the

parameter
you
wish
to
view
(Engine
Speed
or
RPM).
