DiabloSport Trinity Comprehensive User Manual Ver. 2.04 Page 2
AFTERMARKET PARTS‐ Use of the DiabloSport Trinity with aftermarket products is at the owners risk; some
aftermarket products create rich or lean conditions based on design by the product’s manufacturer. It is
impossible to test every possible product so please proceed with caution when using any product related
to adding airflow like throttle bodies, filters and cold air intake kits or boost in the form of pulleys, or
blower upgrades, changes in exhaust systems or exhaust components. Customers with these modifications
may need a custom tune from a DiabloSport CMR dealer. DiabloSport recommends the use of a dyno and
wide band oxygen sensor to monitor data when adding aftermarket products to make the proper tune
changes with Trinity.
Any change in voltage during flash programming procedures WILL interrupt the writing process. Please
disconnect or disable any such add on part. In the event of such an occurrence, unplug the tool, wait 5
seconds and then plug it back in. The tool will recognize that an interrupted writing error has occurred and
will automatically install the original backup. The vehicle is now in its original state. Please attempt to
locate the voltage draw before Trinity is used again. Please feel free to contact DiabloSport directly at any
time with questions related to this process. (800)‐531‐5484 to speak with DiabloSport Tech Support.
IMPORTANT: IT IS NOT NECESSARY TO CONTACT THE VEHICLE MANUFACTURER SHOULD SUCH ERRORS
OCCUR. ANY AND ALL COSTS RELATED TO SUCH ACTIONS ARE THE RESPONSIBILITY OF THE END USER‐ NOT
DIABLOSPORT OR ITS DEALERS.
Important Note: Make sure to remove, disable, or disconnect any of the following (including fuses if
applicable due to possible power draw):
Aftermarket Electrical fans
Shift lights
Aftermarket TV or DVD Players and Speaker Amplifiers
Aftermarket Alarm systems
Trailer Brake Controllers
Aftermarket GPS
On‐Star System Fuses
Screen Care:
Never use abrasive cleaning products.
Don’t use harsh cleaning chemicals
Use a clean lint free terry cloth.
Never use items such as keys or pens to touch the screen.
Remove Trinity from temperatures in excess of 158 degrees or lower than 32 degrees Fahrenheit.
Very important!
Do not perform any tuning or flashing operations with your Trinity while the vehicle is running. The
vehicle must be parked and engine OFF.
Always have all the doors closed while installing the DiabloSport Performance Tune, and keep them
closed until the process is complete.
Do not activate any electrical accessories while installing the DiabloSport Performance Tune. Ensure that
there are no electronic aftermarket accessories wired or plugged into the vehicle that can cause a
substantial voltage drop. Please contact DiabloSport if you are uncertain about the effect of devices that
are installed on your vehicle.
Certain cellular phones or radio equipment might cause interference. Please remove or turn such devices
off while tuning the vehicle.
Do not try to install any tune on a vehicle with a low battery voltage ‐ charge your battery if necessary.
Do not unplug the Trinity while it is installing the DiabloSport Performance Tune or the Original Backup
for ANY reason.
Trinity Tuning: DiabloSport Performance tunes are designed for stock to mildly modified applications. They
are NOT for use with superchargers, turbochargers, or nitrous systems which require proper custom tunes
from a DiabloSport CMR dealer.
Warranty Information
A. DiabloSport Trinity Warranty Policy
a. DiabloSport offers a 30 day satisfaction guarantee on Trinity as well as a 1 year warranty against defects in materials
or workmanship.
b. DiabloSport’s liability under this warranty shall be limited to the correction or replacement of any defective part or
product in question which DiabloSport determines to be necessary.
c. Screen damages will be reviewed on a case by case basis to determine the actual damage done to any screens,
including user error. Warranty freight charges are the responsibility of the dealer, distributor and/or consumer.
d. The Trinity warranty is to the original purchaser and is non‐transferable.
e. This warranty is void unless proof of purchase is submitted.
f. Removal of serial numbers and/or alteration of product or packaging will void all warranties.
g. DiabloSport shall not be held responsible for direct or indirect failures due to the use of our product.
h. DiabloSport shall not credit or repair any units that are not properly restored to the original backup upon time of
return or that may be VIN locked.
i. VIN locked units, or improperly restored units, will be returned to the customer.
ii. It is the customer’s responsibility to check any and all DiabloSport products to make sure they are not VIN locked
before the product shall be returned.
B. Technical Support can be reached by calling toll free (800)‐531‐5484 from 8:30 AM EST through 7:30 EST Mon‐Thurs, and
Friday 9:00 AM EST‐5 PM EST on.
C. Product updates
a. DiabloSport will inform customers of any new updates on our website www.diablosport.com.
b. DiabloSport cannot be held accountable for any or all damages caused by using a Trinity that does not have the latest
software revision, or is outdated.
c. Products that need updates will be handled in the following fashion:
i. DiabloSport will charge a labor and handling fee for products that are deemed non‐defective.
ii. DiabloSport shall decide at time of receipt of RMA if units are defective.
iii. All products returned for update purposes must have a corresponding DiabloSport RMA number for processing‐ all
others will be refused.
D. Returns and RMA/RGA policies and procedures
a. DiabloSport will not warranty, credit, or exchange any product returned without a valid RMA number.
b. All RMA numbers are issued by DiabloSport RMA department.
c. Defective units shall be repaired and returned in like kind. All units that must be re‐furbished to like new condition are
subject to labor and parts charges to be determined by DiabloSport.
d. All refunds for DiabloSport products are at point of purchase‐ DiabloSport will not credit dealers/customers that did
not purchase products directly through DiabloSport.
E. State Law. Some states do not allow limitations of implied warranties, or the exclusion or limitation of incidental, special
or consequential damages, so the above limitations may not apply to you. In such states, liability shall be limited to the
greatest extent permitted by applicable law.
F. Governing Law & Venue. This warranty shall be governed by and construed in accordance with the laws of the State of
Florida, and venue for any legal proceeding or action at law arising out of or construing this Agreement shall lie in the
state or federal courts of Orange County, Florida, and the parties specifically waive any other venue.
G. DISCLAIMER: Not legal for sale or use on any pollution controlled motor vehicles. Legal in California for racing vehicles
ONLY‐ which may never be used upon a highway or other state road.
H. DISCLAIMER: DiabloSport cannot be held liable for any accident or issue caused by users driving while looking at their
Trinity Monitor.
DiabloSport Inc. Satisfaction Guarantee‐ All DiabloSport products have a satisfaction guarantee. If within
the first 30 days from date of purchase you are not satisfied with the results, simply restore the Original
Backup to your vehicle and return the product to the selling dealer. Under no circumstances will
DiabloSport accept the return of a Trinity unit that is VIN locked or has not been restored to original
settings.
Trinity Revisions‐
In such a technology‐based industry, it is sometimes hard to provide our customers with the most
recently updated information. In some cases, by the time our materials are printed, we have already made an update‐
making what you read out of date. DIABLOSPORT works very hard to update our tools to include calibration changes from the
factory, additional features as requested by our customers, and improvements to our tunes on a daily basis if necessary. In
order to keep our customers up to date with releases, applications, product information, vehicle specific questions and
features, we advise you visit our website at www.DIABLOSPORT.com for the most up to date information.
