GPS 5200 Receiver User Guide 57
Third-Party Interface Requirements B
Caterpillar
Cebis Yield
Monitor Claus NMEA GGA 4800
or
9600 8-N-1 1 Hz 50166, or
30945
plus
50581
AGCO
FieIdStar
Yield
Monitor
4
AGCO NMEA GGA, VTG,
GSV, GSA 4800 8-N-1 1 Hz 39903
plus
50581
1 P/N 39903 replaced old Ag Leader cable P/N 30660.
2
Connect to Aux port.
3 Older GreenStars with version 5.3P mapping processor software require 9600 baud. Older GreenStars
with version 5.3R mapping processor software require 4800 baud.
4 AGCO unit requires a null modem RS-232 connection. Ag Leader cable P/N 39903 is wired correctly for
connection.
Hardware Company Protocol NMEA
messages Baud Other Pos
rate Cable
P/N
