3 Installing the Receiver
22 GPS 5200 Receiver User Guide
System components
Check that you have received all components for the GPS 5200 system
that you have purchased. If any containers or components are damaged,
immediately notify the shipping carrier. The following components ar
included:
Optional extra
You may also have ordered the following receiver option:
Mounting the receiver
C
WARNING – For continued protection against the risk of fire, the power
source (lead) to the model GPS 5200 receiver should be provided with a
10 A (maximum) fuse.
Secure the GPS 5200 receiver directly to the mounting plate assembly
(P/N 51312-00) and insert three bolts through the holes that are in the
housing and in the mounting plate assembly. Torque the bolts to
75–80 inch pounds.
Quantity Description
1 GPS 5200 DGPS receiver (P/N 56000-01)
1 System level cable (P/N 50165 or 50166)
1 Mounting plate assembly (P/N 51312-00)
1 Port B plug (P/N 51062)
1 GPS 5200 Receiver User Guide
(this manual, P/N 56100-00-ENG)
Quantity Description
1 RTK capability (P/N 51264)
