GPS 5200 Receiver User Guide 29
Installing the Receiver 3
Port B
This port has the same connector as Port A, see above. Viewed from
outside the receiver, the Port B connector is on the right. It is the port
that is typically used to connect to the SiteNet 900 radio.
8 Port 1 CTS IN
9 Event IN
10 V+ IN
11 V- IN
12 CAN A Low I/O
Pin Name/Function Comments
1 CAN B High I/O
2 Port 2 RS232 Tx OUT
3 Port 2 RS232 Rx IN
4 PPS OUT
5 Signal GND Used for RS232 and other signals.
Should not be connected to V–
(battery negative)
6 Port 2 RTS OUT
or Port 3 RS232 Tx OUT
7 Radar OUT / Alarm OUT
8 Port 2 CTS IN or Port 3
RS232 Rx IN
9 Event IN
10 V+ IN / OUT Maximum output current = 1.25 A
11 V– IN / OUT Maximum output current = 1.25 A
12 CAN B Low I/O
Pin Name/Function Comments
