GPS 5200 Receiver User Guide 55
Third-Party Interface Requirements B
Third-party hardware
The following table lists the interface requirements for connecting a
GPS 5200 receiver to third-party hardware.
Hardware Company Protocol NMEA
messages Baud Other Pos
rate Cable
P/N
AMS Raven NMEA GGA, VTG 9600 8-N-1 1 Hz
50166, or
30945
plus
50581
Ag
Navigator Springhill RTCM 9600 8-N-1 10 Hz
Aim
Navigator Case Tyler NMEA GGA 19200 8-N-1 5 Hz
Contour Position Inc. NMEA GGA 19200 8-N-1 5 Hz
Marker RDS or
Position Inc. NMEA GGA 19200 8-N-1 5 Hz
Falcon Ag Chem NMEA GGA, VTG 4800 8-N-1 1 Hz
Falcon w/
Falcon
Track LBAR Ag Chem NMEA GGA, VTG 19200 8-N-1 10 Hz
50166, or
30945
plus
50581
Swath
Smart or
RGL 500
(LB-5 for
Raven) Raven,
Starlink
manufactured NMEA GGA, VTG
or RMC 19200 8-N-1 10 Hz
LB-3, LB-4,
and LB-5 Starlink NMEA GGA, VTG
or RMC 19200 8-N-1 10 Hz
YM2000
Yield
Monitor
1
Ag Leader NMEA GGA, VTG 4800 8-N-1 1 Hz 39903
plus
50581
PF3000
Yield
Monitor
1
Ag Leader NMEA GGA, VTG 4800 8-N-1 1 Hz 39903
plus
50581
PF3000Pro
Monitor
without
internal
GPS
2
Ag Leader NMEA GGA, VTG 4800 8-N-1 1 Hz 39903
plus
50581
PF
Advantage Ag Leader NMEA GGA, VTG 4800 8-N-1 1 Hz 39903
plus
50581
