GPS 5200 Receiver User Guide 27
Installing the Receiver 3
Note – Do not bend the cable at the Deutsch connector. When you secure
the cable, use the supplied P-Clip. The P-Clip provides additional support
to the connectors and reduces the risk of damage.
When the cable is safely routed and connected to the receiver, use
tie-wraps to secure it at several points, particularly near the base of the
receiver, to prevent straining the connection. Coil any slack cable,
secure it with a tie-wrap, and tuck it into a safe place.
The external device may have to be configured to work with the GPS
5200 receiver. The configuration tools for the external device should be
provided with the device. For more information about configuring the
receiver, see
Chapter 4 . For information about connecting a particular
external device, refer to the manual for that device or contact your local
Reseller.
Note – Use a connector plug (P/N 51062) to cover Port B when that port is
not in use. For example, cover Port B when you are using the receiver in a
non-RTK mode.
