Connecting the system, Vt quick reference guide, Ontrac 2 not supported with isobus – Ag Leader Versa DirectCommand ISOBUS Quick Reference Guides User Manual
Page 6: Quick reference guide
6
VT Quick Reference Guide
Quick Reference Guide
AL: 2006300 - ENG Rev C
CAN A
Guidance
Power
Ethernet
CAN A
Power In
Power Out
Power Control Relay
GPS
Ethernet
CAN B
Guidance
Power
Connection
CAN B IN
CAN B
OUT
Power In
Power Out
Power Control Relay
GPS
CAN A
Existing Tractor
ISOBUS
CAN B IN
CAN B OUT
Existing Tractor
ISOBUS
OnTrac 2+ ISOBUS Installation
OnTrac 2+
Controller
Harness
OnTrac 2
Controller
Harness
Display - Main
Display - Main
Connecting the System
OnTrac 2
NOT supported with
ISOBUS.
