VT Quick Reference Guide
Quick Reference Guide
AL: 2006300 - ENG Rev C
Softkeys
Graphical UI elements
sent by Working Set
Master (WSM) on first
connection with VT.
Size is dependent on
complexity of module UI.
The Object Pool is stored
locally in VT display
memory.
Press to
access
and adjust
implement
settings.
Up to 10
softkeys can
be populated
per screen.
Object Pool
Arrow Button
Advance through multiple screens of
Softkeys.
This button remains hidden unless
more than 10 softkeys are present.
ISOBUS Working Set
One or more
ISOBUS
modules that
control an
implement’s
functionality.
Virtual Terminal Screen
0 . 0 0 . 0
74 . 0 50 . 0
98 . 5 0 . 8
ac ac / hr
Rate
r / min
8
lbs / ac lbs / ac
Command received. Front Meter
Clutch OFF!
0 . 0 0 . 0
l b s / ac l b s / ac
74 . 0 50 . 0
98 . 5
Rate
ac 1
0 . 0
a c / h r
r / min
0
Command received. Front Meter
Clutch OFF!
