3
VT Quick Reference Guide
Quick Reference Guide
AL: 2006300 - ENG Rev C
Caution Icon indicates
module has active trouble
codes (DTCs)
ISO Node Diagnostics
1
2
3
4
C
B
A
A
Equipment Type B
ECU Manufacturer C
Suspect Parameter Number
Error Number
Fault Mode Indicator
Error State
Occurrence Count
Number of times error has occurred
Diagnostic Trouble Code (DTC)
This is SPN + FMI. Reference this
number in the implement owners
manual to diagnose error.
Clears previous active errors
from the history.
CAN Name: 4E 9E 37OC OO
Self Configurable: Yes
Industry Group: Agriculture and Fo
Device Class: Sprayers
Device Class Instance: 0
Function: 128
Function Instance: 0
ECU Instance: 0
Identity Number: 1547854
Manufacturer Code: 97
Ag L
Firmwar
Firmwar
Hardwar
Serial N
Revision: Start Field Operation
Operator:
Configuration
Virtual Terminal Alarm
11:37:10 AM
03/11/2011
134 ISO NODE
233 ISO NODE
CAN A CAN B
Devices
Diagnostics
0 . 0
50 . 0
98 . 5
Rate
0 . 0
ac ac / hr
r / min
0
74 . 0
0 . 0
lbs / ac lbs / ac
Command received . Front Meter
Clutch OFF!
ECU: 5000218*1547854*IMPLEMENT*VT MODULE*AG LEADER TECHNOLOGY*
Software ID: ALTECH, VT ODULE; 01.00.00.00;VT_MODULE_FW;01.00.00.00*
Active Errors: Previously Active Errors:
522102
52366
522102
523666
SPN SPN FMI FMI OC OC
12 12
2 2
1 1
3 3
Clear Prev
Active Errors
Clear Prev
Active Errors
ISO Node Diagnostics
OC
FMI
SPN
