Connecting the system, Vt quick reference guide, Quick reference guide – Ag Leader Versa DirectCommand ISOBUS Quick Reference Guides User Manual
Page 5
5
VT Quick Reference Guide
Quick Reference Guide
AL: 2006300 - ENG Rev C
Display - Main
Connecting the System
CAN
A
Guidance
Power
Ethernet
Power
In
Power Out
Power Control Relay
GPS
Generic ISOBUS Installation
Existing Tractor
ISOBUS
CAN B IN
CAN B OUT
Existing Tractor
ISOBUS
NO
CONNECT
Display - Main
CAN
A
Guidance
Power
Ethernet
Power
In
Power Out
Power Control Relay
GPS
Existing Tractor
ISOBUS
CAN B IN
CAN B OUT
Existing Tractor
ISOBUS
ISOBUS/PareDyme Installation
