VT Quick Reference Guide
Quick Reference Guide
AL: 2006300 - ENG Rev C
Is
4-pin
Power Control
Extension Cable plugged
into display cable and
fully seated?
Troubleshooting Step 3: ISOBUS Retrofit Cable
Start
Plug the ISOBUS CAN
Extension Cable into the
Display Cable until it clicks to
make sure it is fully seated.
Plug 4-pin Power Control
Extension Cable into the
display cable unit it clicks to
make sure it is fully seated.
Is
ISOBUS
CAN Extension
Cable T’d into Display
Cable and fully
seated?
Yes
Yes
No
No
Plug the Active Termination
Cable into power on the ISO
Display Cable until it clicks to
make sure it is fully seated.
Leaving the display power
ON, go to ISOBUS Retrofit
Cable Module Mounting
Location.
Is
the
Active
Termination Cable
plugged into power on ISO
Display Cable and
fully seated?
Are
the 3
LEDs on the
CAN Power Module
Illuminated?
Step 4:
High Current
Relay Module
Yes
No
No
Yes
Enable Virtual Terminal
button from General tab of
Setup screen.
Is
the
implement
plugged into the ISO plug
on the rear of the
tractor?
Yes
No
Go to Step 8:
Cycle Power to
ECU
