Figure 4 Switch Settings window
.
Adding a switch
To add a switch, complete the following steps:
1. Click Switch Settings from the navigation area. The Switch Settings window is displayed in the
main display area.
2. Select one of the following options from the main display area:
• IP Address: If you know the IP address of the switch to scan.
a. Enter the IP address of the switch to be scanned in the IP Address box, as shown in Figure
4 .
b. Select Discover connected switches check box if you want to discover all the connected
switches.
c. Enter the access information, as required, to initiate data capture for the selected switch.
NOTE:
The Brocade switch requires login and password.
d. Select a component group from the Select Component Group drop-down list.
e. Click Add. The switch becomes a part of the named group if it is a valid and supported
switch.
Using SAN Visibility 18
