Adding SAN details
To add SAN details, complete the following steps:
1. Click SAN Settings from the navigation area. The SAN Settings window is displayed in the main
display area. The default SAN name, MySAN, is displayed in the SAN Name box, as shown in
Figure 3 .
If you want to rename the SAN, then enter the name of the SAN that you want to scan in the
SAN Name box.
2. Click Rename. The SAN name appears in the SAN explorer area.
NOTE:
Raw data file generated by SAN Visibility uses the SAN name. For example, if the SAN
Name is MYHP, the raw report file is generated as MYHP.hp at the \
reports
directory.
A Component Group Name is a logical name to represent the collection of connected switches in the
SAN.
To enter the Component Group Name, complete the following steps:
1. Enter the name of your component group in the Component Group Name box. The default
component group name, MyComponentGroup, is displayed in the Component Group Name box,
as shown in
Figure 3 .
2. Click Add. The component group name appears in the SAN explorer area under the SAN name.
NOTE:
To add multiple component groups under the SAN, repeat the steps 1-2.
3. Click Next to enter the switch details.
Supporting switch details
The Switch Settings window enables you to search, add, and modify all the connected switches.
Figure 4 shows the Switch Settings window.
HP StorageWorks SAN Visibility 5.1 User Guide 17
