Diagnostics menu
The DIAGNOSTICS menu allows you to run tests that can help you identify and solve problems with
the product.
To display: Press the Menu button , and then select the DIAGNOSTICS menu.
NOTE: Values that have an asterisk (*) are the factory-default values. Some menu items have no
default.
Item Sub-item Values Description
PRINT EVENT LOG Prints a report containing the last
50 entries in the product’s event
log, starting with the most recent.
SHOW EVENT LOG Displays the last 50 events, starting
with the most recent.
PQ TROUBLESHOOTING Prints a page that includes
instructions, pages for each color,
a demo page, and a configuration
page. These pages can help isolate
print-quality problems.
PRINT DIAGNOSTICS
PAGE Prints a page that can assist in
diagnosing product problems.
DISABLE CARTRIDGE
CHECK This item allows you to remove a
print cartridge to help determine
which cartridge is the source of a
problem.
PAPER PATH SENSORS Performs a test on each of the
product’s sensors to determine if
they are working correctly and
displays the status of each sensor.
PAPER PATH TEST Tests the paper-handling features
of the product, such as the
configuration of the trays.
PRINT TEST PAGE Generates a page for testing the
paper-handling features. You must
define the path for the test in order
to test specific paper paths.
SOURCE ALL TRAYS
TRAY 1
TRAY 2*
TRAY 3
Specifies whether the test page is
printed from all trays or from a
specific tray.
DUPLEX OFF
ON
Determines whether the duplexer
is included in the test.
NOTE: This option is available
only for the HP Color LaserJet
CP3525dn printer and the HP Color
LaserJet CP3525x printer.
