Description LDEV status
Volume is in the
process of being
formatted.
Format
• Product name of the connected external array
• ExG: External LU group number. This appears when you group the LUs from one or more ex-
ternal arrays under a common number.
• Serial: Product serial number.
• Product: Product name.
• Vendor: Vendor name.
• Ex-Dev. Status: Status of the operation executed on the external array, or status of the path
connection. Possible values: Normal, Unknown, Blockade, Warning, Checking, Cache Destage,
and Disconnect. For a description of these values, see
Table 7 .
• LDEV Status: Mapped external LU's status. Possible values: Normal, Unknown, Blockade,
Warning, and Format. For a description of these values, see Table 8 .
• External LU group number
• Characteristic: External LU's identification number.
• Device: External LU's device name.
• Capacity: External LU's capacity in 512-byte blocks.
• Ex-Dev. info.: External array information. When the external array is an XP1024/XP128 or
TagmaStore Workgroup Modular Storage (WMS) array, an asterisk (*) appears.
• VMA: Information about the VMA setting by XP LUN Security Extension. When VMA is set for
the volume, an asterisk (*) appears.
• Alter. Path: Number of configured paths in the format The number of valid paths (the number
of primary alternate paths).
• IO Suppression: I/O Suppression mode: Enable or Disable. For more information, see External
LU attributes set by mapping .
• Cache Mode: Cache mode: Enable or Disable. For more information, see External LU attributes
set by mapping .
• Path: When paths are set, an asterisk (*) appears.
• Group: External LU group number and reference number assigned to each LU in the external
LU group. XP External Storage automatically assigns reference numbers to LUs in the group
when external LUs are mapped. This appears in the format “external LU group number - refer-
ence number of the LU in the group”.
• Ex-Dev. Status: Status of the operation executed to the external array, or status of the path
connection. Possible values: Normal, Unknown, Blockade, Warning, Checking, Cache Destage,
and Disconnect. For a description of these values, see
Table 7 .
• LDEV Status: Mapped external LU's status. Possible values: Normal, Unknown, Blockade,
Warning, and Format. For a description of these values, see Table 8 .
• Progress: When Status is Cache Destage, displays the write process progress, from 1% to
100%.
• Characteristic2: External LU's extended identifying information. This information is used for
identifying logical volumes in the EVA array. For more information, see Identifying logical
volumes of EVA arrays (using Characteristic 2) .
• Discovery
• WWN: World Wide Name identifying the port in the external array that can be set.
XP External Storage panes 70
