External Volume Capacity (KB) = Volume Capacity (number of blocks) × 512 (byte) 1,024
•
Pool capacity
The license capacity of XP Thin Provisioning is calculated using the total capacity of the
XP Thin Provisioning pool. ◦
◦ If you use V-VOLs of XP Thin Provisioning as P-VOLs or S-VOLs of XP Business Copy/XP
Continuous Access/XP Continuous Access Journal, the license capacity of XP Business
Copy/XP Continuous Access/XP Continuous Access Journal is calculated using the page
capacity allocated to the XP Thin Provisioning V-VOLs (that is, used pool capacity).
For instructions on how to calculate pool capacity, see the HP StorageWorks
XP24000/XP20000 Thin Provisioning Software User Guide.
Estimating Licensed Capacity Based on Mounted Capacity
To estimate licensed capacity based on mounted capacity, convert both capacities to the GB unit.
When converting mounted capacity from TB to GB units, multiply by 1,000. On the other hand,
when converting licensed capacity from TB to GB units, multiply by 1,024.
Table 17 Example A of Estimating Capacity for Purchase
Value Item
10.3 TB = 10.3 x 1,000 = 10,300 GB Mounted capacity
10 TB = 10 x 1,024 = 10,240 GB < 10,300 GB
11 TB = 11 x 1,024 = 11,264 GB > 10,300 GB
Licensed capacity
At least 11 TB Estimated capacity for purchase
As shown in Table 18 (page 47) , the required licensed capacity is not always greater than the
mounted capacity. At larger capacities, the difference between the conversion factors (1,000 and
1,024) has a greater (inverse) effect on the equivalent licensed capacity.
Table 18 Example B of Estimating Capacity for Purchase
Value Item
165.62 TB = 165.62 x 1,000 = 165,620 GB Mounted capacity
161 TB = 161 x 1,024 = 164,864 GB < 165,620 GB
162 TB = 162 x 1,024 = 165,888 GB > 165,620 GB
Licensed capacity
At least 162 TB Estimated capacity for purchase
Remote Web Console Options and Licensed Capacity
Table 19 (page 47) lists the options for the Remote Web Console and the licensed capacity type.
Only some of the Remote Web Console options are available to storage partition administrators.
For the available options for storage partition administrators, see the HP StorageWorks
XP24000/XP20000 Disk/Cache Partition User Guide.
Table 19 Remote Web Console Options
Notes Licensed Capacity Option Name
Java application programs that are
downloaded from the SVP to Remote
Web Console. Mounted Capacity Remote Web Console (includes the
Java API and the SNMP Agent)
Used only for open-systems devices. Mounted Capacity LUN Manager
Licensed Capacity 47
