Switch Modules
ServerNet Nomadic Disk User’s Guide—425485-001
4 -8
Switch Card Toggle Switches
Switch Card Toggle Switches
When the key switch on the SCC is turned to the LOCAL position, you change the paths
that fiber-optic signals take through the switch card by moving the toggle switch on the
faceplate of the switch card. The toggle switch does not indicate whether the switch is
straight or crossed, to determine that, refer to
Switch Card LEDs on page 4-9.
Straight Position Crossed position
VST201.vsd
J4
J3
J2
J1 J1
VST 202.vsd
J4
J3
J2
J1 J1
