Table 28 Pool Window Description (continued)
Description Item
•
Protection: Data protection level
SATA-W/V: Write and Verify method on SATA drives
Standard: FC drives, flash drives, external volumes, or
V-VOLs
HP recommends that the data protection level be the
same for pool-VOLs in the same pool.
•
PG: parity group to which the pool-VOL belongs
•
Encryption: Status of volume encryption
Enable indicates the volume is encrypted.
Disable indicates the volume is not encrypted.
Hyphen (-) appears if the volume is other than internal
volumes.
•
Int. VOL Info: drive type of internal volumes. Nothing
will be displayed for FC drives. An asterisk ( * ) will be
displayed for a SATA drive. A dollar sign ( $ ) will be
displayed for an SSD drive. Three consecutive hyphens
(- - -) will display for an external volume.
Pool-VOLs with different drive types cannot be
intermixed in the same pool.
•
Ext. VOL Info: drive type of external volumes. Nothing
will be displayed for FC drives. An asterisk ( * ) will be
displayed for a SATA or BD drive. A dollar sign ( $ )
will be displayed for an SSD drive. Three consecutive
hyphens (-—) will display for an internal volume.
As a best practice, you should specify the same drive
type for all pool-VOLs registered in the same pool.
•
Cache Mode: if the volume is an external volume, cache
mode is displayed. This cache mode is specified when
the external volume is mapped. Pool-VOLs with different
cache modes cannot be intermixed in the same pool.
•
Total Capacity: total capacity of the pool-VOLs in the
pool
• Used LDEVs: total number of the pool-VOLs in the pool
•
Remaining LDEVs: total number of the pool-VOLs that
you can add to the pool
Adds the selected volume(s) in the Free LDEVs list as pool
VOL(s) to the pool that you selected from the Pool tree. Add Pool-VOL button
If you select a CU number from the drop-down list, the
volumes in the CU will be displayed in the Free LDEVs list. LDKC drop-down list
Note that if you select an LDKC from the LDKC drop-down
list, only the CUs in the selected LDKC are displayed.
Among the volumes in the CU which is selected from the
CU drop-down list, the volumes that can be specified as Free LDEVs list
pool-VOLs will be displayed. The following items are
displayed in the list.
•
LDKC:CU:LDEV: LDKC number, CU number, and LDEV
number of the volume
An LDEV number that ends with a # indicates that the
LDEV is an external volume (for example, 00:00:01#).
An LDEV number that ends with the letter X indicates
that the LDEV is a virtual volume used by XP Thin
Provisioning (for example, 00:00:00X). For details
regarding external volumes, see the HP
56 Using the XP Snapshot GUI
