Table 21 Volume List Items (continued)
Description Item
Displays information about P-VOL in
AAA-BB-CCC(XX:YY:ZZ) format. P-VOL
•
AAA: The port ID (cluster and channel number)
•
BB: The group number of the host group
• CCC: LU number
•
XX:YY:ZZ: LDKC number:CU number:LDEV number
An LDEV number that ends with # indicates that the LDEV
is an external volume (for example, 00:00:01#). An LDEV
number that ends with a letter X indicates that the LDEV is
a virtual volume used by Dynamic Provisioning (for
example, 00:00:00X). For details regarding external
volumes, see the HP XP24000/XP20000 External Storage
Software User Guide. For information about XP Thin
Provisioning, see the HP XP24000/XP20000 Thin
Provisioning Software User Guide.
Displays the snapshot ID of an XP Snapshot pair. If the pair
is in SMPL status, three hyphens (- - -) will be displayed. MU
For details about what will be displayed in this item if you
select XP Business Copy pairs, see the HP
XP24000/XP20000 Business Copy Software User Guide.
Displays the status of an XP Snapshot pair or an XP Business
Copy pair. For details about the status of an XP Snapshot Status
pair, see Status of the XP Snapshot Pairs (page 13) . For
details about the XP Business Copy pair status, see the HP
XP24000/XP20000 Business Copy Software User Guide.
Displays information about S-VOL in
AAA-BB-CCC(XX:YY:ZZ) format. S-VOL
•
AAA: The port ID (cluster and channel number)
•
BB: The group number of the host group
• CCC: LU number
•
XX:YY:ZZ: LDKC number:CU number:LDEV number
For LUs with more than one path, only one path is listed.
The path is connected to the first port within the ports
configured to a path that are shown in the tree view of the
Pair Operation Window.
An LDEV number that ends with # indicates that the LDEV
is an external volume (for example, 00:00:01#). An LDEV
number that ends with the letter X indicates that the LDEV
is a virtual volume used by XP Thin Provisioning (for
example, 00:00:00X). For details regarding external
volumes, see the HP XP24000/XP20000 External Storage
Software User Guide. For information about XP Thin
Provisioning, see the HP XP24000/XP20000 Thin
Provisioning Software User Guide.
Displays the consistency group number of the XP Snapshot
pair. When the consistency group is not specified, dotted CTG
lines (- - -) are displayed. For information about what will
be displayed for an XP Business Copy pair, see the HP
XP24000/XP20000 Business Copy Software User Guide.
Displays the status of the S-VOL. When the data is not
written in the S-VOL, (- - -) appears. When the data is SvolMode
written in the S-VOL, W appears. For information about
what is displayed for an XP Business Copy pair, see the
46 Using the XP Snapshot GUI
