Page 37

Status / Description
Description
Item
Green = 10/100 Mbps connection
Orange = 1000 Mbps connection
GbE LAN port for NIC 2
3
N/A
Captive thumbscrew for top cover
4
N/A
Serial port
5
N/A
Low profile/Half length expansion
slot
6
Populated with HP Smart Array E200 controller
Full height/Full length expansion
slot
7
N/A
T10/T15 Wrench
8
N/A
Thumbscrew for PCI cage
9
Blue = Activated
Off = Deactivated
UID LED button
10
N/A
VGA port
11
Blinking green = Ongoing network activity
Green = Existing network link
HP LO100i Management LAN
Port
12
N/A
USB 2.0 ports
13
Green = 10/100 Mbps connection
Orange = 1000 Mbps connection
GbE LAN port for NIC
1/Management
14
N/A
PS/2 keyboard port (purple)
15
HP StorageWorks 400t All-in-One Storage System
The following figures show components, controls, and indicators located on the front and rear panels
of the AiO400t storage system.
HP StorageWorks All-in-One Storage System
37
