Chapter 6. DTE Port Configuration
Hardware Flow Control (HDW FLOW CTRL)
When enabled, the FSU uses CTS to temporarily disable transmit
data to the FSU.
1 PROTOCOL 8 PPP ASYNC
1 DTE PORT 1 2 PHYSICAL LAYER OPTIONS 1 INTERFACE TYPE 1 RS232
2 V.35
1 CONFIG
1 2400 bps
2 DTE PORT 2 2 ASYNCHRONOUS BIT RATE 2 4800 bps
3 9600 bps
4 19.2 Kbps
5 38.4 Kbps
3 DATA BITS 1 7
2 8
4 PARITY 1 NONE
2 EVEN
3 ODD
5 STOP BITS 1 1
2 2
6 HARDWARE FLOW CONTROL 1 OFF
2 ON
3 PROTOCOL OPTIONS N/A
1 IP ADDRESS
4 PROTOCOL ADDRESS TABLE 2 SUBNET MASK
3 PEER IP ADDRESS
4 TRANSMIT RIP REQUESTS
1 NO
5 REPLY TO RIP REQUESTS 2 YES
Figure 6-10
PPP Asynchronous Protocol Menu Tree
Protocol Options
Protocol options are not available when the PPP Asynchronous
protocol is enabled.
