61200.130L1-1
FSU User Manual
5 3
Chapter 6. DTE Port Configuration
Bisync Protocol
The Bisync protocol option enables the FSU to connect IBM
2780/3780 bisync controllers to the host across frame relay. Both
point-to-point and multi-point configurations are supported.
The FSU can decode both ASCII and EBCDIC character sets and
support CRC16, parity, VRC, and LRC error checking methods.
See Figure 6-7 for the Bisync protocol menu tree.
1 PROTOCOL
5 BISYNC
1 DTE PORT 1
2 PHYSICAL LAYER OPTIONS
1 INTERFACE TYPE
1 RS232
1 CONFIG
2 V.35
2 DTE PORT 2
1 2400 bps
2 SYNCHRONOUS BIT RATE
2 4800 bps
3 9600 bps
4 19.2 Kbps
5 38400 bps
6 56000 bps
7 64000 bps
3 SYNCHRONOUS IDLE METHOD
1 TRANSMIT FLAGS
2 TRANSMIT ALL ONES
4 HARDWARE FLOW CONTROL
1 OFF
2 ON
1 PRIMARY
3 PROTOCOL OPTIONS
1 EMULATION TYPE
2 SECONDARY
2 LINE TYPE
1 POINT-TO-POINT
2 MULTIPOINT
3 TRANSLATION CODE
1 EBCDIC CRC 16
2 ASCII CRC16
2 ASCII ODD PARITY VRC, LRC
3 ASCII EVEN PARITY VRC, LRC
4 DATA FORMAT
1 NRZ
5 POLL/RESPONSE TIMEOUT
2 NRZI
6 POLL/RESPONSE TIMER THRESHOLD
7 SLOW POLL RATIO
1 UNIT ADDRESS
2 LLC2 SSAP
4 PROTOCOL ADDRESS TABLE
3 LLC2 DSAP
4 OUTGOING DLCI
Figure 6-7
Bisync Protocol Menu Tree
