FSU User Manual
9
Chapter 2. Installation
Control Port
The eight-position modular jack labeled CONTROL provides
connection to a VT 100 RS-232 compatible interface. This enables
the FSU to be configured through a terminal instead of the front
panel. Use the VT 100 terminal cable (provided) for this connec-
tion. See the appendix Pinouts for the connector pin assign-
ments. A description of the operation of this port is covered in
the chapter Operation.
