Chapter 4. Applications
Table 4-C
Configuration Settings for Multi-Point Bisync Application
HOST FSU REMOTE FSU
DTE Port 1
P r o t o c o l BISYNC BISYNC
Physical CONN=RS232 CONN=RS232
Options RATE=9600 RATE=9600
Protocol LINE=MULTIPOINT LINE=MULTIPOINT
Options TRANS CODE= EBCDIC CRC16 TRANS CODE= EBCDIC CRC16
FORMAT=NRZ FORMAT=NRZ
TIMEOUT=3 TIMEOUT=3
THRESHOLD=10 THRESHOLD=10
POLL RATIO=1 POLL RATIO=1
P r o t o c o l ENTRY #1 ENTRY #2 ENTRY #1
Address Table UNIT ADDR=AA1 UNIT ADDR=BB1 UNIT ADDR=AA1
LLC2 SSAP=04
LLC2 SSAP=04 LLC2 SSAP=04
LLC2 DSAP=04 LLC2 DSAP=08 LLC2 DSAP=04
OUT DLCI=120 OUT DLCI=12 OUT DLCI=17
DTE Port 2
P r o t o c o l BISYNC BISYNC
Physical CONN=RS232 CONN=RS232
Options RATE=9600 RATE=9600
Protocol LINE=MULTIPOINT LINE=MULTIPOINT
Options TRANS CODE= EBCDIC CRC16 TRANS CODE= EBCDIC CRC16
FORMAT=NRZ FORMAT=NRZ
TIMEOUT=3 TIMEOUT=3
THRESHOLD=10 THRESHOLD=10
POLL RATIO=1 POLL RATIO=1
P r o t o c o l ENTRY #1 ENTRY #2 ENTRY #1
Address Table UNIT ADDR=AA1 UNIT ADDR=BB1 UNIT ADDR=BB1
LLC2 SSAP=04
LLC2 SSAP=04 LLC2 SSAP=08
LLC2 DSAP=04 LLC2 DSAP=08 LLC2 DSAP=04
OUT DLCI=120 OUT DLCI=12 OUT DLCI=17
Frame Relay SIGNAL TYPE=ANNEX D SIGNAL TYPE=ANNEX D
Options T 3 9 1 = 1 0 T 3 9 1 = 1 0
N 3 9 1 = 6 N 3 9 1 = 6
N 3 9 2 = 3 N 3 9 2 = 3
N 3 9 3 = 4 N 3 9 3 = 4
