FSU User Manual
61200.130L1-1
Chapter 6. DTE Port Configuration
No control lead status or break characters are transmitted across the
frame relay network.
Physical Layer Options
Interface Type (CONN)
Select the connector type for the DTE interface. The choices are
V.35 and RS-232.
Asynchronous Bit Rate (BIT RATE)
Select the operating speed to match the DTE device connected to
the FSU. The selections are 2400 bps, 4800 bps, 9600 bps, 19.2
kbps, and 38.4 kbps.
Data Bits
Select the byte length to match the DTE device connected to the
FSU. The choices are 7 and 8.
Parity
Select even, odd, or no parity information. Set to match the DTE
device connected to the FSU.
Stop Bits
Select one or two stop bits. Set to match the DTE device con-
nected to the FSU.
Hardware Flow Control (HDW FLOW CTRL)
When enabled, the FSU uses CTS to temporarily disable transmit
data to the FSU.
Protocol Options
Protocol options are not available when the Transparent Async
protocol is selected.
Protocol Address Table
Far End Port Number (FE PORT)
Enter the remote FSU port number that the remote device is
connected to.
