61200.130L1-1 FSU User Manual 5 9
Chapter 6. DTE Port Configuration
Outgoing DLCI (OUT DLCI)
Enter the DLCI address that identifies the virtual circuit used to
connect with the remote FSU.
PPP Synchronous Protocol (PPP SYNC)
PPP Synchronous protocol provides a PPP device access to the
frame relay network and also routes IP traffic from the network
to the PPP device. See Figure 6-9 for the PPP synchronous menu
tree.
Routing
Routing tables are formed through a combination of RIP and
static route entries. If RIP is used, routing tables are generated
dynamically. With static routing, the user is able to force rela-
tionships. Static route tables are configured through the IP
Routing selection in the CONFIG menu.
Static routing requires additional configuration (see the chapter IP
Routing
for more information).
The port set for PPP Synchronous protocol routes and supports IP
traffic only.
