5 4
FSU User Manual
61200.130L1-1
Chapter 6. DTE Port Configuration
Physical Layer Options
Interface Type (CONN)
Select the connector type for the DTE interface. The choices are
V.35 and RS-232.
Synchronous Bit Rate (RATE)
Select the operating speed of the DTE interface. These selections
are dependent upon the Network Port speed.
Speed selections made for the Network Port affect the choices available
for the DTE ports.
Synchronous Idle Method (IDLE)
Enable the FSU to transmit flags or all ones.
Hardware Flow Control (HDW FLOW CTRL)
When configured for the Bisync protocol, this parameter is
always enabled. The FSU uses commands within the bisync
protocol to temporarily disable transmit data to the FSU.
Protocol Options
Emulation Type (EMUL TYPE)
For multi-point configurations, this entry defines primary or
secondary emulation. Set the FSU connected to the host to
secondary and the FSU connected to the 2780/3780 controller to
primary.
Line Type (LINE)
Select a point-to-point or multi-point line type.
Translation Code
Define the character set and error checking algorithm to use.
The choices are EBCDIC CRC16, ASCII CRC16, ASCII odd parity
VRC/LRC, and ASCII even parity VRC/LRC.
Data Format (FORMAT)
Set the data format used by your equipment. The choices are
non-return-to zero (NRZ) and non-return-to-zero inverted
(NRZI).
