Chapter 25: Enterprise VoIP Network Management
AltiWare ACM 5.1 Administration Manual 353
• The target system needs to have the hop-off restriction reference properly
configured. The reference extension is set on the Call Restriction tab in System
Configuration, and then that reference extension cannot have Internal Calls Only
checked on the Restriction tab of Extension Configuration.
To configure Global Least Cost Routing
1. Click the Global LCR Button.
2. On the Global LCR screen, click the Add button. The Add Route dialog box appears:
3. Fill in the dialog box, and click OK.
4. After adding a route, click Edit, check the Enable check box, and click OK to
activate the Global LCR route.
Parameter Description
Enable Check this check box to enable the configuration.
E.164 Number
Pattern E.164 is the ITU standard format for international
telephone numbers. Enter a country code and area
code. For example, the number pattern for a site in
Fremont, Calif., would be 1510 (the country code 1,
followed by the Fremont area code 510).
Source Site Select the server from which the call originates, or
select All Servers.
Target Site Select the server that receives the call.
