Chapter 11 Avaya P330 Layer 2 Features
Avaya P334T-ML User’s Guide 101
LAG Implementation in the Avaya P330 Family of Products
This section describes the implementation of the LAG feature in the P330 Family of
products.
With the P334T-ML, you can aggregate the two GBIC ports to form a LAG, you can
aggregate the bandwidths of 6 groups of up to 8 10/100BaseT ports in a LAG, for a
maximum of 7 LAGs per switch.
The relationship between the P334T-ML Port Numbers and the LAG logical Port
Number that will be assigned to each LAG is depicted below.
Panel Ports in the LAG Max. Number of LAGs LAG Logical Port Number
1-4, 25-28 1 101
5-8, 29-32 1 102
9-12, 33-36 1 103
13-16, 37-40 1 104
17-20, 41-44 1 105
21-24, 45-48 1 106
51,52 1 107
