Virtual Private Network
36
— .bin files (for example: 0625C7C.bin)
• Java Virtual Machine (JVM) version 1.2 or later must be installed on
your PC. To check, click Start-> Settings-> Control Panel-> Java to
see if JVM is installed on your machine and the version of it. If it is not
installed, contact your system administration to help you to install it.
To download the latest JVM, go to
www.java.com .
• Ensure that your PC has a firewall that allows incoming
communication to the following ports:
— UDP Port 69 (TFTP)
— TCP Port 80 (HTTP)
— UDP Port 49000
Note: The Avaya Phone VPN Configuration Wizard.jar file creates a
log.txt file during execution. This file is helpful to troubleshoot
problems you experience using the Avaya Phone VPN Configuration
Wizard.jar. The log.txt file is located in the same directory as
Avaya Phone VPN Configuration Wizard.jar.
Connecting your IP Deskphone
Before you connect your IP Deskphone to your PC, ensure that
components of your IP Deskphone are connected properly.
Connect your IP Deskphone using one of the following methods:
• connect to your modem. See Figure 4 on page 37 .
• connect to your router. See Figure 5 on page 37 .
• connect to your wireless access point and modem. See Figure 6 on
page 38 .
