6 Parameterisation
BU 0020 GB-2612 63
6.2.2 Extra functions
Parameter
{factory setting}
Setting value / Description / Note Device Supervisor Parameter set
Pos: 99 /Anleitungen/5. Parametrierung/Parameter/P500-P599/Parameter P507 – PPO-Typ @ 0\mod_1328091974415_388.docx @ 11042 @ @ 1
P507
PPO-Type
(PPO-Type)
1 ... 4
{ 1 }
This parameter can only be used with the technology unit Profibus, DeviceNet or InterBus.
See also the relevant section of the corresponding supplementary BUS manual.
Pos: 100 /Anleitungen/5. Parametrierung/Parameter/P500-P599/Parameter P508 – Profibus-Adresse @ 0\mod_1328092017167_388.docx @ 11065 @ @ 1
P508
Profibus address
(Profibus address)
1 ... 126
{ 1 }
Profibus address, only with the technology unit Profibus
See also the additional description for the Profibus control BU 0020
Pos: 101 /Anleitungen/5. Parametrierung/Parameter/P500-P599/Parameter P509 – Quelle Steuerwort @ 0\mod_1328092104264_388.docx @ 11088 @ @ 1
P509
Source Control Word
(Source control word)
0 ... 10
{ 0 }
Selection of the interface via which the FI is controlled.
0 = Control terminals or keyboard control ** with the ControlBox (if P510=0), the
ParameterBox (not ext. p-box) or via BUS I/O Bits.
1 = Only control terminals , the FI can only be controlled via the digital and analog inputs or
via the bus I/O Bits.
2 = USS control word *, the control signals (enable, direction of rotation, ...) are transferred
via the RS485 interface. The setpoint is transferred via the analog input or the fixed
frequencies.
Above SK 540E this setting should also be selected if communication via Modbus RTU is
intended. The frequency inverter automatically detects whether this is a USS protocol or
a Modbus protocol.
3 = CAN control word *
4 = Profibus control word *
5 = InterBus control word *
6 = CANopen control word *
7 = DeviceNet control word *
8 = Ethernet TU*** control word*
9 = CAN Broadcast *
10 = CANopen Broadcast *
*) Keyboard control (ControlBox, ParameterBox, PotentiometerBox) is blocked,
parameterisation is still possible.
**) If the communication during keyboard control is interrupted (time out 0.5 sec),
the FI will block without an error message.
***) The Ethernet TU setting must be used for all NORD Ethernet-based bus systems (e.g.:
EtherCAT: SK TU3-ECT, PROFINET: SK TU3-PNT).
Note: Parameterisation of a frequency inverter via a field bus connection requires
parameter (P509) "Control Terminals" to be set to the appropriate bus system
Pos: 102 /Anleitungen/5. Parametrierung/Parameter/P500-P599/Parameter P510 – Quelle Sollwerte @ 0\mod_1328092251176_388.docx @ 11111 @ @ 1
NOTE:
For details about the respective Bus systems please
refer to the respective Options descriptions.
BU 0020 = Profibus BU 0050 = USS,
Modbus RTU
BU 0060 = CAN/CANopen BU 0070 = InterBus
BU 0080 = DeviceNet BU 0090 = AS-Interface
BU 0570 = EtherCAT BU 0590 = ProfiNet
