Configuration level
Configuration parameters
42
8840 profiler
Name
Value range Description
Default
m.Loc
Blockage of hand function
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
Err.r
Reset of all error list entries
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
6
Ò - key switches
Pid.2
Switching of parameter set (Pb, ti, td)
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
P.run
Programmer-Run/Stop (see Page 68)
0
0
no function
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
P.off
Programmer off. Internal set-point is effective (see Page 68)
0
0
no function
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
I.Chg
Switching of the actual process value between Inp1 and X2
0
0
no function (switch-over via interface is possible)
2
DI1 switches
3
DI2 switches (only visible with OPTION)
4
DI3 switches (only visible with OPTION)
5
è - key switches
di.Fn
Function of digital inputs (valid for all inputs)
0
0
direct
1
inverse
2
toggle key function
fDI1
Forcing di1 (only visible with 8800/8840 Configurator!)
0
0
No forcing
1
Forcing via serial interface
fDI2
Forcing di2 (only visible with 8800/8840 Configurator!)
0
0
No forcing
1
Forcing via serial interface
