Instruction Manual CyberComm 6000
39
You may perform any of the following activities for the selected channel/parameter:
ƒ Carry out measurements
ƒ Take a snap shot of a graph (Refer page 43)
ƒ Perform a fresh standardization or switch to a different standardization
ƒ Setup channel/parameter (Refer CyberScan instruction manual)
ƒ Configure display criteria (Refer CyberScan instruction manual)
ƒ Configure storage criteria (Refer CyberScan instruction manual)
ƒ Configure print criteria (Refer CyberScan instruction manual)
4.2.2 Selecting Multiple Channels
You can view multiple channel measurement screens, configure channel/parameter,
setup display, storage & print criteria of multiple channels by just selecting channels
and its parameter from the Measure tab.
To select multiple channels:
1. In the Measure control tab, click on the Multi Channel check box to select it.
2. Click on the first channel you want to select. Click on the channel button again if
you wish to unselect.
Example:
3. Click on the parameter icon of your interest in the selected channel.
Example:
4. Repeat step 2 & 3 for other channels you wish to select.
5. The right-pane (workspace) displays the measuring screen of the selected
parameters of each of the channels. (Figure 34).
6. Click any of the tabs shown in the bottom of the workspace to switch to other
screens of the selected channel/parameters (Figure 33).
You may perform any of the following activities for the selected channels/parameters:
ƒ Carry out measurements
ƒ Log measurement data (Refer page 41)
ƒ Setup channel/parameter (Refer CyberScan instruction manual)
ƒ Configure display criteria (Refer CyberScan instruction manual)
ƒ Configure storage criteria (Refer CyberScan instruction manual)
ƒ Configure print criteria (Refer CyberScan instruction manual)
Note: Standardization is available only in single-channel mode.
