Instruction Manual CyberComm 6000
37
4. Measurements
4.1 About Measurement
CyberComm lets you carry out measurements just as if you were using your
CyberScan meter by providing the same look and feel screens & buttons. In addition,
CyberComm enables you to quickly access and switch between single-channel,
multi-channel, standardization, setup, display criteria, storage criteria and print criteria
screens.
With CyberComm, you can keep records of multiple electrodes & standardization and
switch between them whenever you need.
It is important to standardize the CyberScan meter/electrode or import existing
standardization data from the meter, before you start making any measurement.
4.2 Measure Tab
In Measure tab, you do your measurements, calibrations (standardizations), setting
up channel parameters, configure display, storage & print criteria.
Click to switch to Measure control tab.
The measure tab lets you:
ƒ Select between single-channel & multi-channel
ƒ Select channels and their measuring parameters
4.2.1 Selecting a Single Channel
You can view single channel measurement screen, configure a single channel, setup
display, storage & print criteria of a single channel by just selecting the channel and
its parameter from the Measure tab.
To select a single channel:
1. Make sure that the Multi Channel check box is not selected in the Measure
control tab.
2. Click on the channel button you want to select. (Click on the channel button again
if you wish to unselect.)
Example:
3. Click on the parameter icon of which you wish to measure/standardize/setup.
Example:
